The Details
For all of your portable PA needs!
FREEONEX is an all-in-one battery-powered personal PA system featuring multiple inputs and BLUETOOTH connectivity. Hosted in a compact, lightweight yet ultra-durable polypropylene cabinet with multiple aiming positions, it represents the perfect solution for musicians, DJs and general PA users
An array of three high-definition 2” HF speakers coupled with a powerful 6” LF woofer provides a consistent tonal balance, a strong output level over distance and a wide coverage of large audiences.
The state-of-the-art electronics includes a sophisticated pre-amp section with DSP processor and a powerful 150W + 50W Class D power amplifier. The built-in 2 mono + 1 stereo channel digital mixer allows to connect two microphones or instruments and a stereo player, each one with independent level controls. A 2-band EQ and a studio-grade digital REVERB is also available for microphone/instrument inputs.
The built-in BLUETOOTH connection allows to stream high quality audio from portable devices without the need of any cable. Also, the built-in Li-ion battery provides up to 10 hours of mains-free continuous operation, for the maximum freedom of use.
Specifications
System Type
- 2-way vented enclosure with HF array
Acoustic Components
- High-Frequency Driver: 3 x 2 in
- Low-Frequency Driver: 1 x 6 in
Performance
- Frequency Response (-3 dB): 60 Hz – 18 kHz
- Max SPL: 115 dB
- Coverage Angle (H x V): 120° x 50°
Power
- Total Peak Power: 400 W
- HF: 50 W (Class D)
- LF: 150 W (Class D)
Inputs & Outputs
- 2 x XLR/TRS Combo (balanced)
- 1 x 3.5mm Jack Stereo
Output Connectors:
- 1 x 6.35mm Jack (unbalanced)
- 1 x USB Type A (Charge Port)
Channels & Controls
- 2 x MIC/LINE
- 1 x LINE/BT
Mic/Line Controls:
- Reverb
- Low
- High
- Level
Stereo In/Bluetooth Controls:
- Pair
- Level
Processing & Connectivity
- DSP Processing: 32-bit DSP, 24-bit AD/DA
- Bluetooth: Protocol 5.0, Audio Streaming
Physical Design
- Enclosure Material: Polypropylene
- Finish: Black Textured
- Grille Material: Powder-Coated Steel
- Handles: 1 x Top
- Mounting Pole: 1 x Bottom
- Dimensions (H x W x D):
- 320 mm x 240 mm x 290 mm
- 12.59 in x 9.45 in x 11.42 in
- Weight: 7.5 kg (16.53 lb)
Power & Battery
- Power Supply: 100 – 240 V~, 50 / 60 Hz
- Power Consumption: 150 W
- Battery Type: Rechargeable Lithium-Ion (6000mAh)
- Battery Play Time (Medium Level): Up to 10 hours
- Recharging Time: Less than 4 hours
- USB Charging: 1 A max
The Essentials
- Brand: Proel
- Model Number: FREEONEXWH
- Mo's Secret Code: N255230
- Colour: White
- Wattage: 200w+
